ECO-SAFE PARK
ECO-ROAD SAFETY
Road safety accessories made from recycled rubber.
Corner protectors for parking areas
ECO-SAFE PARK: Recycled Rubber Corner Guards for Parking Lots and Garages
With ECO-SAFE PARK, we offer a recycled rubber corner guard made from end-of-life tires, designed to protect pillars, walls, and other edges adjacent to parking areas. High-visibility reflective inserts on both sides make the profile more visible; installation can be done by gluing or anchoring with dowels, and the element can be cut to size as needed.
Visibility
Reflective strips on both sides
Laying
Gluing or doweling
Adaptation
Can be cut to size
recycled rubber derived from end-of-life tires.
Dimensions
, 1000 × 95 × 25 mm.
Weight: 3.5 kg per piece.
Colour: Black.
Application: Corners of piers and walls.
01 / Product
Protecting the corners of pillars and walls
ECO-SAFE PARK is designed to absorb the impact caused by accidental contact between bumpers and doors and the edges found in parking and maneuvering areas.
The corner guard is made of recycled rubber derived from end-of-life tires. The reflective inserts on both sides improve the visibility of the protected corner, while the ability to cut the product allows its length to be adjusted to suit installation needs.
What does it protect?
Corners of pillars and walls adjacent to parking areas.
How can you tell?
With high-visibility reflective strips on both sides.
How does it fit?
It can be cut to size when the standard length is not suitable for the application.
02 / Applications
Where to Install ECO-SAFE PARK
ECO-SAFE PARK is designed to protect the corners of pillars and walls in areas designated for vehicle parking and maneuvering.
Public and Private Parking Lots
Protection of corners in areas designated for vehicle parking.
Garages and Carports
Corners of pillars and walls in garages, carports, and covered parking areas.
Multi-level parking garages
Protection of sharp edges along internal parking and maneuvering routes.
Maneuvering Areas
Sharp edges near the areas where vehicles pass during maneuvers.
03 / Specifications
Dimensions and Technical Specifications for ECO-SAFE PARK
Key information for verifying the dimensions, shape, and weight of the corner guard before selecting and installing it.
| Element Length | Profile width | Thickness | Useful inner side | Weight |
|---|---|---|---|---|
| 1,000 mm | 95 mm | 25 mm | 70 mm per side | 3.5 kg |
Color: black.
Visibility: High-visibility reflective strips on both sides.
04 / Installation
Installation of ECO-SAFE PARK
ECO-SAFE PARK can be installed by gluing or anchoring, with the method chosen based on the material of the surface to which it is applied. When the standard length of 1,000 mm needs to be adjusted to fit the edge to be protected, the profile can be cut to size using standard cutting tools.
Installation and CUTTING
Adhesive bonding: specified as one of the methods for securing the product.
Tiling: an alternative recommended depending on the material to which ECO-SAFE PARK is applied.
Cutting to size: possible when necessary using standard cutting tools; the catalog lists an angle grinder with a rotating blade as an example.
05 / FAQ
FAQs About ECO-SAFE PARK
Straightforward answers about the dimensions, installation, fit, and color of the corner trim.
What are the dimensions of ECO-SAFE PARK?
The component is 1,000 mm long; the profile is 95 mm wide and 25 mm thick. Each component weighs 3.5 kg.
How do you install ECO-SAFE PARK?
The catalog lists two installation methods: gluing or anchoring with wall anchors, to be chosen based on the substrate material.
Can ECO-SAFE PARK be cut to size?
Yes. When necessary, the profile can be cut to length using standard cutting tools; the catalog lists a rotary blade cutter as an example.
What color is ECO-SAFE PARK?
ECO-SAFE PARK is black and features high-visibility reflective strips on both sides.
Technical and Commercial Inquiry
Request information about ECO-SAFE PARK
To accurately assess your order, please let us know the number of edges to be protected, the type of surface on which the product will be installed, and the quantity required. We can provide you with the technical and commercial information needed to determine the best solution.
